Fitness Note Sorting Machine
Matrix 8130Features
- Touch-screen TFT colour display
- Detects Mutilation: dog ears, hole, cut, torned, soiled, and taped notes
- Software upgrade via USB, SD card or LAN
What is in the box
cable display(Opt) Fuse Manual
MATRIX 8128-SF SPECIFICATIONS
| Counting speed | 800~1200 notes/min |
|---|---|
| Hopper capacity | 500 notes (continuous feeding) |
| Stacker capacity | 220 notes |
| Rejection Pocket capcity | 50 notes |
| Detection Technology | Twin CIS, UV, MG, MT, IR, 2D & 3D |
| Fitness Detection | Tape, Soiled, Holes, Graffiti, Unfit, Mutilated notes |
| Noise | ≤60Db |
| Power supply | 100-240V AC,50/60Hz 3.0A |
| Power consumption | ≤50W |
| Dimensions | 251(L)*271(W)*264(H)mm |
| Weight | 8.5 Kg |
| Interface | RS-232, Printer, USB, SD card, LAN (optional) |
